| Swing Distance | 26″ | Minimum Spindle Speed | 20 RPM |
| Distance Between Centers | 120″ | Cross Slide Travel | 14-1/2″ |
| Horsepower | 15 hp | Swing Over Gap | 37″ |
| Voltage | 220 V/460 V | Tailstock Taper | 5MT |
| Phase | 3 Phase | Model No | SK26120 |
| Spindle Taper | 5MT | Spindle Type | A2-8 |
| Spindle Hole Diameter | 4-1/8″ | Swing Over Crossslide | 17″ |
| Weight | 9,000 lbs | Inch Thread Range | 2-28 TPI (36 changes) |
| Maximum Spindle Speed | 1,200 RPM | Metric Thread Range | 0.80-14 mm (37 changes) |
Product Features
| Remarks | •Totally enclosed universal gearbox
•2 Speed tailstock quill
•Halogen work light
•Hardened and ground bed ways
•Inch/metric dual dials
•12″ Steady rest w/roller jaws
•Foot brake
•Flood coolant
•Automatic bed stops
•Gap bed
•Feed rod with clutch
•4-way tool post
•Automatic and manual lubrication to bed ways and slide ways
•Hardened and ground headstock gears and shafts
•110 Volt controls with no volt release and E-stop
•Machines are dual 230/460 voltage, wired for 230 volt
•ONE YEAR WARRANTY | Country of Origin | Taiwan |
Shipping Info
Shipping Notes
Ships by Truck. Additional Costs Apply.
Package Weight
9000.000
