| Drill Bit Size / Cutting Diameter (DC) | 1.25 mm | Shank Standard | DIN6535-HA |
| Drill Bit Size / Cutting Diameter (DC) - Inch | 0.0492″ | Tool Type | Solid Carbide Micro Drill |
| Decimal Equivalent | 0.0492″ | Flute Type | Helical |
| Drill Bit Size / Cutting Diameter (DC) - Metric | 1.25 mm | Grade | X0BU |
| Length Group | 5xD | Point Shape | Split |
| Coating | Uncoated | Measurement Type | Metric |
| Applicable Material | Multi-materials | Style | Twist Drill |
| Application | Micro Drilling | Series/List # | 462.1..A0-XM (RR 51200) |
| Connection Diameter Machine Side (DCONMS) | 3 mm | Usable Length (LU) | 6.325 mm |
| Coolant Supply Property (CSP) | External | Length Chip Flute (LCF) | 8.2 mm |
| Point Angle (SIG) | 130 Degrees | Overall Length (OAL) | 38 mm |
| Point Length (PL) | 0.291442 mm | Flute Count (NOF) | 2 |
| Functional Length (LF) | 37.71 mm | Cutting Direction (HAND) | Right Hand |
| Shank Length (LS) | 26.2166 mm | Body Material | Solid Carbide |
| Shank Type | Cylindrical |
Product Features
| Country of Origin | SWITZERLAND |
Shipping Info
Package Weight
0.011
